GPS Tracker
LCT400D
LCT400D is a 4G full netcom vehicle positioning terminal carefully built for vehicle networking, which integrates 4G full netcom wireless communication technology and satellite navigation and positioning technology. With ACC detection, DC detection, power-off alarm, overspeed alarm, mileage statistics, electronic fence and other functions. With the global positioning service platform, the real-time acquisition of vehicle data, tracking and positioning functions are realized. It can be widely used in the insurance industry, corporate fleet industry, automobile manufacturers/4S stores, individual users, electric new energy fields, passenger vehicles, taxis, rental vehicles, etc.
|
|
|
Specifications
|
|
Power Supply Mode
|
Battery power supply
|
|
Operating Voltage
|
DC 9V - 95V
|
|
Operating Current
|
12V/average 50mA
|
|
Sleep Current
|
12V/less than 15mA
|
|
Built-in Battery Capacity
|
180 mAh (3.7V polymer battery) optional
|
|
Operating Temperature
|
-30 ℃ ~ +75 ℃
|
|
Storage Temperature
|
-40 ℃ ~ +80 ℃
|
|
Humidity
|
10%-85% RH non-condensing
|
|
Positioning Method
|
satellite positioning
|
|
Cold Start Time
|
average of 32 seconds
|
|
Hot Start Time
|
1 second average
|
|
Tracking Sensitivity
|
-162 dBm
|
|
Frequence Range
|
L1: 1575.42±1.023MHz
B1: 1561.098±2.046MHz
|
|
Positioning Aaccuracy
|
<10m(1σ)
|
|
Timing Accuracy
|
<30ns(1σ)
|
|
Speed Measurement Accuracy
|
<0.1m/s(1σ)
|
|
High Input
|
2-way ACC detection, etc.
|
|
Low Input
|
3-way SOS emergency alarm, etc.
|
|
High Output
|
2 5V output, etc.
|
|
Low Output
|
2-way remote oil and electricity cut-off, etc.
|
|
Microphone
|
1 external microphone (optional)
|
|
Horn
|
1 external speaker (optional)
|
|
TTL/232/485
|
1 default TTL interface (can be customized as: RS232 or RS485)
|
|
Host Size (length, width and height)
|
87mm * 64mm * 24mm
|
|
Shell Material
|
metal
|
|
Host Weight
|
145g
|
|
|
