BD Locator
LCT700D
LCT700D is a 4G full netcom vehicle positioning terminal carefully built for car networking, which integrates 4G full netcom wireless communication technology andBeidousatellite navigation and positioning technology. With ACC detection, DC detection, power-off alarm, overspeed alarm, mileage statistics, electronic fenceand other functions. With the global positioning service platform, the real-time acquisition of vehicle data, tracking and positioning functions are realized. It can be widely used in the insurance industry, corporate fleet industry, automobile manufacturers/4S stores, individual users, electric new energy fields, passenger vehicles, taxis, rental vehicles, etc.
|
|
|
|
Specifications |
|
|
Power Supply Mode |
Battery power supply |
|
Operating Voltage |
DC 9V - 45V |
|
Operating Current |
12V/average 50mA |
|
Sleep Current |
12V/less than 15mA |
|
Built-in Battery Capacity |
180 mAh (3.7V polymer battery) optional |
|
Operating Temperature |
-30 ℃ ~ +75 ℃ |
|
Storage Temperature |
-40 ℃ ~ +80 ℃ |
|
Humidity |
10%-85% RH non-condensing |
|
Positioning Method |
satellite positioning |
|
Cold Start Time |
average of 32 seconds |
|
Hot Start Time |
1 second average |
|
Tracking Sensitivity |
-162 dBm |
|
Frequency Range |
B1I: 1561.098±2.046 MHz B1C: 1575.420±16.368 MHz |
|
< 1.5m (CEP50) |
|
|
Timing Accuracy |
< 30ns (1σ) |
|
Speed Measurement Accuracy |
< 0.1m/s(1σ) |
|
High Input |
2-way ACC detection |
|
Low Input |
3-way SOS emergency alarm |
|
High Output |
2-way output |
|
Low Output |
2-way remote oil and electricity cut-off |
|
Microphone |
1 external microphone (optional) |
|
Horn |
1 external speaker (optional) |
|
TTL/232/485 |
1 default TTL interface (can be customized as: RS232 or RS485) |
|
Host Size (length, width and height) |
87mm * 64mm * 24mm |
|
Shell Material |
metal |
|
Host Weight |
145g |
