GPS Tracker
LCT300D
LCT300D is a carefully crafted car networking 4G Netcom vehicle positioning terminal, integrated 4G Netcom wireless communication technology and satellite positioning technology, the terminal adopts industrial-grade highly integrated full built-in antenna design, equipment built-in 3axis sensor, intelligent power saving wake-up work. has DC detection,ACC detection, power failure alarm, overspeed alarm, mileage statistics, remote fuel cut-off, electronic fenceand other functions. With the global positioning service platform, the real-time acquisition of vehicle data, tracking and positioning functions are realized.is widely used in the insurance industry, corporate fleet industry, automobile manufacturers/4S stores, individual users, electric new energy fields, passenger vehicles, taxis, rental vehicles, etc.
|
|
|
|
Specifications |
|
|
Power Supply Mode |
Battery power supply |
|
Operating Voltage |
DC 9V - 95V |
|
Operating Current |
12V/average 35mA |
|
Sleep Current |
12V/average 10mA |
|
Built-in Battery Capacity |
60 mAh (3.7V polymer battery) optional |
|
Operating Temperature |
-20 ℃ - 75 ℃ |
|
Storage Temperature |
-30 ℃ - 80 ℃ |
|
Humidity |
10%-85% RH non-condensing |
|
Positioning Method |
satellite positioning |
|
Cold Start Time |
average of 32 seconds |
|
Hot Start Time |
1 second average |
|
Tracking Sensitivity |
-162 dBm |
|
Frequency Range |
L1: 1575.42±1.023MHz B1: 1561.098±2.046MHz |
|
Positioning Accuracy |
<10m(1σ) |
|
Timing Accuracy |
<30ns(1σ) |
|
speed measurement accuracy |
<0.1m/s(1σ) |
|
Oil and electricity cut-off |
can be outsideto one relay |
|
ACC detection input |
ACC test port 1 way |
|
Host size (length, width and height) |
83mm * 33mm * 13.5mm |
|
Shell material |
ABS plastic |
|
Host weight |
35g |
|
|
|
